CADLink V5 Features for Profilers

Naturally, CADLink V5 supports "Step-and-Repeat" arrays for multiple copy part cutting. You can also call up outlines of your (searchable) stock of plates and offcuts, to ensure best usage of material, and reduce scrap.

For creating nests of dissimilar parts, CADLink V5 lets you apply a "bump-zone" (shown here in dark blue) around a single item, or a group of items, thus making it easy to place parts at a predetermined safe distance from its neighbours. Optionally CADLink V5 supports Auto-Nesting.

It's an eye-opener
